Standard：ANSI B16.5-1973、JPI-75-15-70、GB 699、GB1220、JB755、HG20633-97
Material of RTJ:
|
Material |
Maximum Hardness |
Temperature（ ℃ ） |
Abbreviations |
|
|
Brinell |
Rockwell“B”Grade |
|||
|
Soft Iron |
90 |
56 |
-60～500 |
D |
|
Low Carbon Steel |
120 |
68 |
-40～540 |
S |
|
SS304 |
160 |
83 |
-250～540 |
304 |
|
SS304L |
160 |
83 |
-250～540 |
304L |
|
SS316 |
160 |
83 |
-200～815 |
316 |
|
SS316L |
160 |
83 |
-200～815 |
316L |
|
SS321 |
160 |
83 |
-200～870 |
321 |
|
SS347 |
160 |
83 |
-200～870 |
347 |
|
SS410 |
170 |
86 |
-40～850 |
410 |
|
5Cr-0.5Mo |
130 |
|
-29～650 |
|
|
Copper |
80 |
|
-100～315 |
|
|
Aluminum |
35 |
|
-200～425 |
|
|
Inconel 600 |
150 |
|
-100～1095 |
|
|
Incoloy 825 |
150 |
|
-100～1095 |
|
|
Monel 400 |
150 |
|
-100～760 |
|
|
Titanium |
215 |
|
-200～540 |
|
|
Nickel 200 - |
110 |
|
200～760 |
|
|
Hastelloy B2 |
230 |
|
-100～1095 |
|
|
Hastelloy C276 |
210 |
|
-100～1095 |
|
Warning: Gasket materials should never be recommended when both the temperature and the pressure are at the maximums listed. Properties and applications shown are typical. No application should be undertaken by anyone without independent study and evaluation for suitability. Never use more than one gasket in one flange joint, and never reuse a gasket. Improper use or gasket selection could cause property damage and/or serious personal injury. The data reported is a compilation of field testing, field service reports and/or in-house testing. While the utmost care has gone into publishing the information contained herein, we assume no responsibility for errors. The information and specifications contained in this website are subject to change without notice. This revision cancels and obsoletes all previous editions.
